DeWalt 5-HP 60-Gallon Two-Stage Air Compressor (230V 1-Phase)
Model: DXCMV5076055
+
Share This Product
-
Product Description
-
13Reviews
-
2Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Grade
Style
CFM
15.3
CFM Rated @ 100 PSI
Tank Size
60
Gallons
Grade
Consumer
CFM
15.3 CFM Rated @ 100 PSI
Tank Size
60 Gallons
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
Features
Features
- Industrial DeWalt Two-Stage Air Compressor
- Provides enough power to operate more than one air tool or device at one time
- Equipped with tank pressure gauge and on/off switch for maximum reliability
- 5-HP Electric Motor With Thermal Overload Protection
- Low pump RPM for longer life
- T.O.P.S. protects the motor from voltage fluctuations; Magnetic starter not required
- Patented Cast Iron Industrial Duty Pump
- Provides 15.3 CFM at 100 PSI for big jobs & multiple users
- Industrial style air intake filter and large oil level sight glass for easy maintaining
- Patented Cast Iron Flywheel & Asymmetrical, Deep Groove Cooling Fins
- Large fins for low pump RPM, improved cooling, longer pump life
- Cooler pumps last longer & run more effectively with patented fins
- 60-Gallon Air Tank
- ASME rated for safety; 175 PSI maximum pressure
- Manual oil drain with 4” extension simplifies maintenance
- 4 tie down holes in platform for ease in transporting
- 2-Year Manufacturer Factory Pump Warranty
- 1-year Factory Warranty on all other parts
- Shipped with Synthetic Blend Compressor Oil
- Pump Warranty Extension
- Purchase & use of maintenance kit doubles the pump warranty
Specifications
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
No
Amp Draw
22
Recommended Breaker
30 Amp Breaker
Engine
HP
5
Pump
CFM
15.3
CFM Rated @
100 PSI
Pump Material
Solid Cast Iron
Max PSI
175 PSI
Oil Sight Glass
Yes
Pump Type
Two-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
60 Gallons
Tank Outlet
3/4 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Accessories
Pressure Gauge
Yes
Air Dryer
No
Overview
Weight
424 Pounds
Certification
ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
40 Inches
Product Width
31 Inches
Product Height
80 Inches
Power Type
Electric
UPC
846212053966
Grade
Style
CFM
15.3
CFM Rated @ 100 PSI
Tank Size
60
Gallons
Grade
Consumer
CFM
15.3 CFM Rated @ 100 PSI
Tank Size
60 Gallons
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
Features
Features
- Industrial DeWalt Two-Stage Air Compressor
- Provides enough power to operate more than one air tool or device at one time
- Equipped with tank pressure gauge and on/off switch for maximum reliability
- 5-HP Electric Motor With Thermal Overload Protection
- Low pump RPM for longer life
- T.O.P.S. protects the motor from voltage fluctuations; Magnetic starter not required
- Patented Cast Iron Industrial Duty Pump
- Provides 15.3 CFM at 100 PSI for big jobs & multiple users
- Industrial style air intake filter and large oil level sight glass for easy maintaining
- Patented Cast Iron Flywheel & Asymmetrical, Deep Groove Cooling Fins
- Large fins for low pump RPM, improved cooling, longer pump life
- Cooler pumps last longer & run more effectively with patented fins
- 60-Gallon Air Tank
- ASME rated for safety; 175 PSI maximum pressure
- Manual oil drain with 4” extension simplifies maintenance
- 4 tie down holes in platform for ease in transporting
- 2-Year Manufacturer Factory Pump Warranty
- 1-year Factory Warranty on all other parts
- Shipped with Synthetic Blend Compressor Oil
- Pump Warranty Extension
- Purchase & use of maintenance kit doubles the pump warranty
Specifications
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
No
Amp Draw
22
Recommended Breaker
30 Amp Breaker
Engine
HP
5
Pump
CFM
15.3
CFM Rated @
100 PSI
Pump Material
Solid Cast Iron
Max PSI
175 PSI
Oil Sight Glass
Yes
Pump Type
Two-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
60 Gallons
Tank Outlet
3/4 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Accessories
Pressure Gauge
Yes
Air Dryer
No
Overview
Weight
424 Pounds
Certification
ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
40 Inches
Product Width
31 Inches
Product Height
80 Inches
Power Type
Electric
UPC
846212053966
Product Specs
+−
Specifications
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
No
Amp Draw
22
Recommended Breaker
30 Amp Breaker
Engine
HP
5
Pump
CFM
15.3
CFM Rated @
100 PSI
Pump Material
Solid Cast Iron
Max PSI
175 PSI
Oil Sight Glass
Yes
Pump Type
Two-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
60 Gallons
Tank Outlet
3/4 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Accessories
Pressure Gauge
Yes
Air Dryer
No
Overview
Weight
424 Pounds
Certification
ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
40 Inches
Product Width
31 Inches
Product Height
80 Inches
Power Type
Electric
UPC
846212053966
Product Q&A
(2)
+−
Search Product Q&A's
Answered by Joshua. the Air Compressor Expert
+−
What is the RPM of this compressor and what is the decibel rating?
Rod R.
from New York
April 16, 2020
Answer
The RPM of the motor is 3450 and the RPM of the pump is 767. Unfortunately the manufacturer does not provide us with the decibel rating of this compressor. A common decibel rating for a piston compressor is around 80 decibels (+/- depending on its surroundings).
Was this answer helpful?
Yes
0
No
0
+−
Can this unit be wired with 208 volt and work properly?
Rob
from Maryland
January 23, 2018
Answer
I'm sorry to bring bad news to you, but it is very difficult and expensive to convert this unit to another voltage. You will normally need to have a device called a buck booster installed by a certified electrician. If you have any other questions about this or other products from our website, don't hesitate to give us a call. We're here to help.
Was this answer helpful?
Yes
0
No
0
