MEGA 5-HP 60-Gallon Single-Stage Air Compressor (208/230V 1-Phase - 150 PSI)
Model:
MP-6560VB
+
Share This Product
Similar Products
$1,099.00
$1,399.00
$1,064.00
$1,389.00
$1,202.00
$1,399.00
$1,269.00
$1,049.00
Recommended Accessories
Expert Recommended Accessories
Selected by Melissa, our Expert
Optional Accessories
6
Model: 21999-0177
$116.10
In-Stock
Model: TRI-GD-1100P-GL
$65.00
Factory-Direct
Model: MP284701AV
$31.00
Factory-Direct
Model: TRI-GD-2100P-GL
$95.00
Factory-Direct
$248.00
Factory-Direct
Model: 21999-0424
$405.00
Factory-Direct
Features
Grade
Consumer
Style
Single Stage 1-Phase
CFM
18
Tank Size
60
- MEGA Single-Stage Air Compressor
- Perfect for DIY projects to the professional air compressor user
- Heavy-Duty 5-HP Induction Motor
- 208/230-volt single-phase motor
- Provides maximum performance and efficiency
- Delivers 18 CFM @ 90 PSI: Max 150 PSI
- Plenty of power to run a wide range of air tools
- Tackle airbrushing, drilling, sanding and bolting/wrenching
- Cast Iron V-Twin Oil Lubricated Pump
- Thermally stable cast iron cylinder body
- Aluminum head and machine cast iron valve plate
- Aluminum pump head helps dissipate heat for longer pump life
- "W" Design
- Minimizes vibration, improves cooling, extends compressor life
- One-Piece Cast Iron Crankcase
- Durable automotive-style ball bearings
- Stainless steel reed valves for increased volumetric efficiency
- 60-Gallon Vertical Tank
- Fully enclosed belt guard protects you and the belt
- Easy-access manual drain simplifies routine maintenance
- Easy Viewing Oil Sight Glass On Pump
- Easily check compressors pump oil level
- Conveniently accessible oil fill for fast maintenance
- 1-Year Limited Manufacturer Warranty
- Protect your investment
- Shipped with 100% full synthetic air compressor oil
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov
Specifications
MP-6560VB
General Information
Product Category
Air Compressor - Stationary
Motor
Voltage
208-230 Volt AC
Phase
1-Phase
Magnetic Starter
Magnetic Starter
The Magnetic Starter is the "thinking cap" for the motor of the air compressor. Magnetic starters are electromagnetically operated switches that provide a safe method for certain motors to be started under a large motor load.
No
Amp Draw
18
Recommended Breaker
30 Amp Breaker
Engine
HP
5
Pump
CFM
CFM
Cubic Feet Per Minute, which indicates the compressor's flow rate - or the amount of air that a compressor can produce at a given pressure level. Typically compressors that have higher CFM ratings are able to provide more air, which makes them ideal for larger applications
18
CFM Rated @
90 PSI
Pump Material
Cast Iron w/ Aluminum Head
Max PSI
Max PSI
PSI, or Pounds Per Square Inch, measures the amount of pressure placed on a square inch of space. In compressor terms, PSI is the amount of force that an air compressor can deliver
150 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
After Cooler
After Cooler
An aftercooler is a mechanical heat exchanger designed to remove the heat and moisture of compression from a compressed air stream so the air is cool and dry enough for use in air-operated equipment. A compressed air aftercooler has three primary functions: Cool the air discharged from the air compressor
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
Pump Low Oil Shut-off
Prevents the air compressor from operating or restarting without an adequate amount of oil in the compressor
No
Tank
Tank Size
60 Gallons
Tank Included
Yes
Tank Outlet
1/2 Inch
Electronic Drain Valve
Electronic Drain Valve
The inexpensive and reliable electric drain valve (EDV) automatically removes condensate from your air system. It has an integral strainer to prevent clogging and saves time and money by eliminating the need for manual draining
No
Tank Orientation
Vertical
Accessories
Pressure Gauge
Yes
Air Dryer
No
Overview
Product Category
Air Compressor - Stationary
Weight
418 Pounds
Certification
ASME
Consumer Warranty
1 Year
Product Length
24 Inches
Product Width
23 Inches
Product Height
74 Inches
Power Type
Electric
UPC
376204971492
Reviews
(50)
MEGA Compressor MP-6560VB Reviews & Ratings
Customer Photos and Videos
Customer Rating
4.83
(35 Ratings)
88% recommend this product
5
(31)
(31)4(3)
(3)3(0)
(0)2(1)
(1)1(0)
(0)Mega Compressor
By Isaac
Washington
Review Posted 11/22/2025
Looks awesome in my garage, and can't beat the price for the high CFM you get.
Isaac Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I39d Buy It Again
Cons:
None
Amazing Quality
By Deano
Texas
Purchased 11/13/2025 |
Review Posted 11/21/2025
Just WOW! At first, I was amazed at the price, but the quality is outstanding at even the highest price! No more overpaying for the name! There's a new sheriff in town, and his name is Mega!
Deano Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I39d Buy It Again, Easy To Store
Cons:
None
New Compressor
By John C.
South Carolina
Purchased 10/31/2025 |
Review Posted 11/19/2025
We finally got around to replacing our terribly old 20-gallon 2.5 HP unit that made more noise than anything.
Got this installed this week and am very pleased with its operation and reduced noise level.
Got this installed this week and am very pleased with its operation and reduced noise level.
John C. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, I39d Buy It Again
Great Air Compressor For The Price!
By Nicholas K
California
Purchased 10/10/2025 |
Review Posted 11/14/2025
Finally got the unit wired and installed. As everyone says it’s fairly quiet for what it is, it puts out a great amount of air. I think it filled up in 3-4 min. Delivery was very smooth and came in perfect condition with no damage. I like this compressor so far I would definitely recommend it for a garage or small shop. Remember it doesn’t come with a wire, I used 10awg
Nicholas K Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Price, High Quality, Features, Quiet
Cons:
None
Garage
By Terry G.
North Carolina
Purchased 10/14/2025 |
Review Posted 11/14/2025
In planning and building my dream garage, many things that I wanted to ensure was that I had an air compressor that would be affordable, reliable, and long-lasting. After much research, I chose the Mega Compressor from Air Compressor Direct. They had the best price, fast shipping, and great customer service. I highly recommend Air Compressor Direct.
Terry G. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Mega Machine
By Jeremy S.
South Dakota
Purchased 10/14/2025 |
Review Posted 11/12/2025
So far, it is wired up and running properly. No complaints.
Jeremy S. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Price, I39d Buy It Again
Cons:
None
Upgrade For Garage Hobbyist
By Nicholas K.
California
Purchased 10/10/2025 |
Review Posted 11/08/2025
The compressor hasn’t been wired yet but it seems like a very solid unit. Delivery was a breeze with the lift gate option and came undamaged and on a wooden pallet. Everything looks well built and from what I hear these are pretty quiet when running. Can’t wait to get working on some projects and see what I can handle.
Nicholas K. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Price, Easy To Store, High Quality
Cons:
None
Mega Air Compressor
By Bobs Welding
Wisconsin
Purchased 10/07/2025 |
Review Posted 11/05/2025
This is a great compressor. It pumps up from 125psi to 155 psi a lot faster than I had expected. Cost was a big factor in my buying this compressor. It is quality built. The only downfall is the crating. There is nothing supporting the top of the compressor. But it did come undamaged and on time. I would highly recommend this compressor.
Bobs Welding Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Price, I39d Buy It Again, High Quality, Exceeded Expectations
Cons:
Packaging
Big Air Upgrade
By Josh A.
Michigan
Purchased 10/08/2025 |
Review Posted 11/05/2025
This moves a lot of air and does a great job keeping up with tool and spray gun usage in my shop. A couple of issues- the mounting screws holding the pump on were not tightened at the factory- they were finger tight, and one of them fell out during shipping, and I had to replace it. Also, the oil drain plug was painted over, so I had to chip away at the paint to be able to remove it. The location of the drain plug is very inconvenient- It's basically impossible to do an oil change without making a huge mess. Overall, though, the performance for the price is worth overcoming these issues.
Josh A. Recommends This
Was this review helpful?
Rating Breakdown
4/5
3/5
5/5
4/5
Pros:
Price, I39d Buy It Again
Cons:
Bad Instructions
Mega 5 HP Single Stage Air Comprressor
By Bobs Welding
Wisconsin
Purchased 10/07/2025 |
Review Posted 10/29/2025
This is a great compressor. It pumps up fast. Creating needs to be a little better, very flimsy, not much protection, but it came undamaged and shipped on time. This is my main compressor running air tools and a plasma cutter.
Bobs Welding Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Price, High Quality, Durable, Exceeded Expectations
Cons:
