BelAire 2-HP 60-Gallon Dual-Voltage Single-Stage Air Compressor
Model: 2061V
+
Share This Product
-
Product Description
-
20Reviews
-
2Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Grade

Style

CFM
7.1
CFM Rated @ 100 PSI
Tank Size
60
Gallons
Grade
Consumer
CFM
7.1 CFM Rated @ 100 PSI
Tank Size
60 Gallons
Features
Features
- Cast Iron Pump
- More durable and longer life than aluminum pumps
- 2-HP Motor Dual-Voltage Motor (115/230 Single-Phase)
- Long lasting for maximum performance and reliability
- 60-Gallon Vertical Tank
- Rugged receiver tank to improve consistency of air flow
- Fully Enclosed Belt Guard
- Provides added safety during operation
- Added Features
- Start/Stop pressure switch control
- ASME safety and tank valves
- Tank drain and discharge valve
- Dual Voltage
- If running on 120V needs a 20 amp breaker
- Please consult a qualified electrician for installation
- Plug not included; you will need to choose the plug based on your installation
Specifications
Motor
Voltage
120/240 Volt AC
Phase
1-Phase
Magnetic Starter
No
Amp Draw
Consult Certified Electrician
Recommended Breaker
Consult Certified Electrician
Engine
HP
2
Pump
CFM
7.1
CFM Rated @
100 PSI
CFM @ 40 PSI
8.3
Pump Material
Solid Cast Iron
Max PSI
135 PSI
Oil Sight Glass
No
Pump Type
Single-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
60 Gallons
Tank Outlet
1/4 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Filter
Regulator
No
Accessories
Pressure Gauge
Yes
Air Dryer
No
Overview
Weight
256 Pounds
Certification
ASME
Consumer Warranty
1 Year
Product Length
30 Inches
Product Width
22 Inches
Product Height
68 Inches
Power Type
Electric
Grade

Style

CFM
7.1
CFM Rated @ 100 PSI
Tank Size
60
Gallons
Grade
Consumer
CFM
7.1 CFM Rated @ 100 PSI
Tank Size
60 Gallons
Features
Features
- Cast Iron Pump
- More durable and longer life than aluminum pumps
- 2-HP Motor Dual-Voltage Motor (115/230 Single-Phase)
- Long lasting for maximum performance and reliability
- 60-Gallon Vertical Tank
- Rugged receiver tank to improve consistency of air flow
- Fully Enclosed Belt Guard
- Provides added safety during operation
- Added Features
- Start/Stop pressure switch control
- ASME safety and tank valves
- Tank drain and discharge valve
- Dual Voltage
- If running on 120V needs a 20 amp breaker
- Please consult a qualified electrician for installation
- Plug not included; you will need to choose the plug based on your installation
Specifications
Motor
Voltage
120/240 Volt AC
Phase
1-Phase
Magnetic Starter
No
Amp Draw
Consult Certified Electrician
Recommended Breaker
Consult Certified Electrician
Engine
HP
2
Pump
CFM
7.1
CFM Rated @
100 PSI
CFM @ 40 PSI
8.3
Pump Material
Solid Cast Iron
Max PSI
135 PSI
Oil Sight Glass
No
Pump Type
Single-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
60 Gallons
Tank Outlet
1/4 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Filter
Regulator
No
Accessories
Pressure Gauge
Yes
Air Dryer
No
Overview
Weight
256 Pounds
Certification
ASME
Consumer Warranty
1 Year
Product Length
30 Inches
Product Width
22 Inches
Product Height
68 Inches
Power Type
Electric
Product Specs
+−
Specifications
Motor
Voltage
120/240 Volt AC
Phase
1-Phase
Magnetic Starter
No
Amp Draw
Consult Certified Electrician
Recommended Breaker
Consult Certified Electrician
Engine
HP
2
Pump
CFM
7.1
CFM Rated @
100 PSI
CFM @ 40 PSI
8.3
Pump Material
Solid Cast Iron
Max PSI
135 PSI
Oil Sight Glass
No
Pump Type
Single-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
60 Gallons
Tank Outlet
1/4 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Filter
Regulator
No
Accessories
Pressure Gauge
Yes
Air Dryer
No
Overview
Weight
256 Pounds
Certification
ASME
Consumer Warranty
1 Year
Product Length
30 Inches
Product Width
22 Inches
Product Height
68 Inches
Power Type
Electric
Product Q&A
(2)
+−

Search Product Q&A's
Answered by Joshua. the Air Compressor Expert
+−
So I should be able to plug it in a 120v outlet with a 20 amp breaker, correct? Will the compressor run slower because of it?
Fernando
from Texas
December 13, 2018
Answer
According to the manufacturer, they recommend using a 30-amp breaker for both 120 volts and also 240 volts. The compressor will not run slower at 120 volts but it will not run as efficiently (electricity-wise). The higher the voltage, the more efficiently a motor runs.
Was this answer helpful?
Yes

0
No

0
+−
What is the duty cycle on this unit
Richard Mohler
from Louisiana
April 12, 2016
Answer
Most manufacturers do not state the duty cycle of their compressors, but a 50% duty cycle is common for most consumer grade compressors.
We recommend sizing the compressor 1.25-1.5 times the CFM of your tool for continuous operation. If the compressor does not produce enough air volume, CFM, then the pressure will drop.
Reciprocating (Piston) compressors are not designed for continuous or 100% duty cycle. The compressor will cycle off & on if it is sized correctly.
We recommend sizing the compressor 1.25-1.5 times the CFM of your tool for continuous operation. If the compressor does not produce enough air volume, CFM, then the pressure will drop.
Reciprocating (Piston) compressors are not designed for continuous or 100% duty cycle. The compressor will cycle off & on if it is sized correctly.
Was this answer helpful?
Yes

0
No

0
