BelAire 5-HP 60-Gallon Two-Stage Air Compressor (230V 1-Phase)
Model: 216V
+
Share This Product
-
Product Description
-
40Reviews
-
4Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Grade

Style

CFM
15.3
CFM Rated @ 90 PSI
Tank Size
60
Gallons
Grade
Consumer
CFM
15.3 CFM Rated @ 90 PSI
Tank Size
60 Gallons
Features
Features
- Two-Stage Solid Cast Iron Pump
- Designed for superior quality & extends the life of the pump
- Compact Design
- Ideal for work environments where space is a premium
- 5-HP Single-Phase Motor (230V)
- Saves $$$, No need to purchase additional starter
- 60-Gallon ASME Certified Vertical Air Tank
- 100% factory tested at full pressure; 15.3 CFM at 90 PSI
- High Flow Belt Guard
- Fully enclosed design provides added safety
- Oil Level Sight Glass
- Easily check the oil level at any time
- Start-Stop Pressure Switch Control
- Saves time and energy
- Stainless Steel Valves
- Extends the life of the compressor
- 2 Year Full Warranty
- Protects your investment
Specifications
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
No
Amp Draw
Consult Certified Electrician
Recommended Breaker
40 Amp Breaker
Engine
HP
5
Pump
CFM
15.3
CFM Rated @
90 PSI
Pump Material
Solid Cast Iron
Max PSI
165 PSI
Oil Sight Glass
Yes
Pump Type
Two-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
60 Gallons
Tank Outlet
1/2 Inch
Tank Orientation
Vertical
Overview
Weight
300 Pounds
Certification
ASME
Consumer Warranty
2 Years
Product Length
29 Inches
Product Width
20 Inches
Product Height
68 Inches
Power Type
Electric
Grade

Style

CFM
15.3
CFM Rated @ 90 PSI
Tank Size
60
Gallons
Grade
Consumer
CFM
15.3 CFM Rated @ 90 PSI
Tank Size
60 Gallons
Features
Features
- Two-Stage Solid Cast Iron Pump
- Designed for superior quality & extends the life of the pump
- Compact Design
- Ideal for work environments where space is a premium
- 5-HP Single-Phase Motor (230V)
- Saves $$$, No need to purchase additional starter
- 60-Gallon ASME Certified Vertical Air Tank
- 100% factory tested at full pressure; 15.3 CFM at 90 PSI
- High Flow Belt Guard
- Fully enclosed design provides added safety
- Oil Level Sight Glass
- Easily check the oil level at any time
- Start-Stop Pressure Switch Control
- Saves time and energy
- Stainless Steel Valves
- Extends the life of the compressor
- 2 Year Full Warranty
- Protects your investment
Specifications
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
No
Amp Draw
Consult Certified Electrician
Recommended Breaker
40 Amp Breaker
Engine
HP
5
Pump
CFM
15.3
CFM Rated @
90 PSI
Pump Material
Solid Cast Iron
Max PSI
165 PSI
Oil Sight Glass
Yes
Pump Type
Two-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
60 Gallons
Tank Outlet
1/2 Inch
Tank Orientation
Vertical
Overview
Weight
300 Pounds
Certification
ASME
Consumer Warranty
2 Years
Product Length
29 Inches
Product Width
20 Inches
Product Height
68 Inches
Power Type
Electric
Product Specs
+−
Specifications
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
No
Amp Draw
Consult Certified Electrician
Recommended Breaker
40 Amp Breaker
Engine
HP
5
Pump
CFM
15.3
CFM Rated @
90 PSI
Pump Material
Solid Cast Iron
Max PSI
165 PSI
Oil Sight Glass
Yes
Pump Type
Two-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
60 Gallons
Tank Outlet
1/2 Inch
Tank Orientation
Vertical
Overview
Weight
300 Pounds
Certification
ASME
Consumer Warranty
2 Years
Product Length
29 Inches
Product Width
20 Inches
Product Height
68 Inches
Power Type
Electric
Product Q&A
(4)
+−

Search Product Q&A's
Answered by Joshua. the Air Compressor Expert
+−
What is the duty cycle time of this compressor?
Wes
from California
November 20, 2019
Answer
75% duty cycle.
Was this answer helpful?
Yes

0
No

0
+−
Where/who is the BelAire pump manufacturer?
Cameron M.
from Texas
October 26, 2019
Answer
Atlas Copco is the manufacturer and they are made in Italy.
Was this answer helpful?
Yes

0
No

0
+−
What is the oil capacity of the model 216V?
Robert M.
from Missouri
July 02, 2019
Answer
BelAire does not provide a capacity for the crankcase. They state that the oil level should be 1/2 to slightly higher in the oil sight glass.
Was this answer helpful?
Yes

0
No

1
+−
What amperage breaker do I need for the Belaire 216V?
Michael
from Missouri
May 24, 2015
Answer
The manufacture recommends a 40 amp breaker.
Was this answer helpful?
Yes

0
No

0
