C-Aire 5-HP 80-Gallon Two-Stage Air Compressor (208-230V 3-Phase)

C-Aire 5-HP 80-Gallon Two-Stage Air Compressor (208-230V 3-Phase)
Model: A050V080-3230
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Discontinued
Sorry, this product is no longer available
Free Freight
Free Freight
Lift Gate Services
Lift Gate Service
*We currently CANNOT ship this product to Alaska, Hawaii or any destination outside of the United States
Share
  • Product Description
  • Reviews
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Grade
Commercial
Style
CFM
17
CFM Rated @ 175 PSI
Tank Size
80
Gallons
Grade
Commercial
CFM
17 CFM Rated @ 175 PSI
Tank Size
80 Gallons
Features
Features
  • Solid Cast Iron Cylinder 2 Stage Pump
  • Delivers 17 CFM at 175 PSI; 200 PSI maximum
  • Rugged components provide long-lasting dependability
  • Low 885 RPM extends pump life, runs quieter
  • Finned Inter-Stage Cooling
  • Improves cooling & efficiency for optimum pump performance
  • 5-HP Heavy Duty Motor
  • Pre-wired magnetic starter for simple installation
  • Ideal for farm, small auto repair or auto body shop
  • 80 Gallon Vertical Tank
  • ASME certified for reliability & safety
  • Fully Enclosed Belt Guard
  • Protects the belt & operator
  • Manual Air Tank Drain
  • Makes tank easy to maintain
  • 208-230 Volt, 40-Amp, Three Phase Power
  • Easily wires into either your 208V or 230V, 3-phase system
  • INSTALL-80V installation kit recommended (not included)
  • 1 Year Factory Warranty
  • Extends to 3 years with AX-V95 & registration (sold separately)
Specifications
Motor
Voltage
208-230 Volt AC
Phase
3-Phase
Magnetic Starter
Yes
Amp Draw
Consult Certified Electrician
Recommended Breaker
Consult Certified Electrician
Engine
HP
5
Pump
CFM
17
CFM Rated @
175 PSI
Pump Material
Solid Cast Iron
Pump Type
Two-Stage
Max PSI
200 PSI
Oil Sight Glass
Yes
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
80 Gallons
Tank Outlet
1/2 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Overview
Certification
ASME
Weight
550 Pounds
Product Length
34 Inches
Product Width
24 Inches
Product Height
70 Inches
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Power Type
Electric
Grade
Commercial
Style
CFM
17
CFM Rated @ 175 PSI
Tank Size
80
Gallons
Grade
Commercial
CFM
17 CFM Rated @ 175 PSI
Tank Size
80 Gallons
Features
Features
  • Solid Cast Iron Cylinder 2 Stage Pump
  • Delivers 17 CFM at 175 PSI; 200 PSI maximum
  • Rugged components provide long-lasting dependability
  • Low 885 RPM extends pump life, runs quieter
  • Finned Inter-Stage Cooling
  • Improves cooling & efficiency for optimum pump performance
  • 5-HP Heavy Duty Motor
  • Pre-wired magnetic starter for simple installation
  • Ideal for farm, small auto repair or auto body shop
  • 80 Gallon Vertical Tank
  • ASME certified for reliability & safety
  • Fully Enclosed Belt Guard
  • Protects the belt & operator
  • Manual Air Tank Drain
  • Makes tank easy to maintain
  • 208-230 Volt, 40-Amp, Three Phase Power
  • Easily wires into either your 208V or 230V, 3-phase system
  • INSTALL-80V installation kit recommended (not included)
  • 1 Year Factory Warranty
  • Extends to 3 years with AX-V95 & registration (sold separately)
Specifications
Motor
Voltage
208-230 Volt AC
Phase
3-Phase
Magnetic Starter
Yes
Amp Draw
Consult Certified Electrician
Recommended Breaker
Consult Certified Electrician
Engine
HP
5
Pump
CFM
17
CFM Rated @
175 PSI
Pump Material
Solid Cast Iron
Pump Type
Two-Stage
Max PSI
200 PSI
Oil Sight Glass
Yes
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
80 Gallons
Tank Outlet
1/2 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Overview
Certification
ASME
Weight
550 Pounds
Product Length
34 Inches
Product Width
24 Inches
Product Height
70 Inches
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Power Type
Electric
Product Specs
+
Specifications
Motor
Voltage
208-230 Volt AC
Phase
3-Phase
Magnetic Starter
Yes
Amp Draw
Consult Certified Electrician
Recommended Breaker
Consult Certified Electrician
Engine
HP
5
Pump
CFM
17
CFM Rated @
175 PSI
Pump Material
Solid Cast Iron
Pump Type
Two-Stage
Max PSI
200 PSI
Oil Sight Glass
Yes
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
80 Gallons
Tank Outlet
1/2 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Overview
Certification
ASME
Weight
550 Pounds
Product Length
34 Inches
Product Width
24 Inches
Product Height
70 Inches
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Power Type
Electric
