DeWalt 7.5-HP 80-Gallon Two-Stage Air Compressor (230V 1-Phase)
Model: DXCMV7518075
+
Share This Product
-
Product Description
-
2Reviews
-
Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Grade
Style
CFM
21.2
CFM Rated @ 175 PSI
Tank Size
80
Gallons
Grade
Contractor
CFM
21.2 CFM Rated @ 175 PSI
Tank Size
80 Gallons
Features
Features
- 7.5 HP Baldor Electric Motor
- 4 pole, 1725 RPM, NEMA rated for reliability
- Conveniently equipped with pre-wired & mounted magnetic starter
- Patented Two Stage Cast Iron Industrial Duty Pump
- Provides 21.2 CFM at 175 PSI for big jobs & multiple users
- Patented Cast Iron Flywheel
- Large fins for low pump RPM, improved cooling, longer pump life
- High Efficiency Finned Copper Intercooler
- Cooler pumps last longer & run more effectively
- Extra Capacity Oil Reservoir
- Ensures lower oil temperatures for longer pump life
- 4 Rings Per Piston
- Improved volumetric efficiencies & oil control
- 80 Gallon Air Tank
- ASME rated for safety; 175 PSI maximum pressure
- Uniquely Designed Metal Belt Guard
- Improves pump cooling up to 60°F over other designs
- 2 Year Limited Factory Warranty
- Purchase & use of maintenance kit doubles the pump warranty
- Protects your investment
Specifications
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
Yes
Amp Draw
31
Recommended Breaker
40 Amp Breaker
Engine
HP
7.5
Pump
CFM
21.2
CFM Rated @
175 PSI
Pump Material
Solid Cast Iron
Max PSI
175 PSI
Oil Sight Glass
Yes
Pump Type
Two-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
80 Gallons
Tank Outlet
3/4 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Overview
Weight
623 Pounds
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
37 Inches
Product Width
29 Inches
Product Height
79 Inches
Power Type
Electric
UPC
846212009345
Grade
Style
CFM
21.2
CFM Rated @ 175 PSI
Tank Size
80
Gallons
Grade
Contractor
CFM
21.2 CFM Rated @ 175 PSI
Tank Size
80 Gallons
Features
Features
- 7.5 HP Baldor Electric Motor
- 4 pole, 1725 RPM, NEMA rated for reliability
- Conveniently equipped with pre-wired & mounted magnetic starter
- Patented Two Stage Cast Iron Industrial Duty Pump
- Provides 21.2 CFM at 175 PSI for big jobs & multiple users
- Patented Cast Iron Flywheel
- Large fins for low pump RPM, improved cooling, longer pump life
- High Efficiency Finned Copper Intercooler
- Cooler pumps last longer & run more effectively
- Extra Capacity Oil Reservoir
- Ensures lower oil temperatures for longer pump life
- 4 Rings Per Piston
- Improved volumetric efficiencies & oil control
- 80 Gallon Air Tank
- ASME rated for safety; 175 PSI maximum pressure
- Uniquely Designed Metal Belt Guard
- Improves pump cooling up to 60°F over other designs
- 2 Year Limited Factory Warranty
- Purchase & use of maintenance kit doubles the pump warranty
- Protects your investment
Specifications
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
Yes
Amp Draw
31
Recommended Breaker
40 Amp Breaker
Engine
HP
7.5
Pump
CFM
21.2
CFM Rated @
175 PSI
Pump Material
Solid Cast Iron
Max PSI
175 PSI
Oil Sight Glass
Yes
Pump Type
Two-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
80 Gallons
Tank Outlet
3/4 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Overview
Weight
623 Pounds
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
37 Inches
Product Width
29 Inches
Product Height
79 Inches
Power Type
Electric
UPC
846212009345
