EMAX 7.5-HP Tankless Rotary Screw Air Compressor with Variable Speed Drive (460V 3-Phase)
Model: ERV0070003-460
+
Share This Product
-
Product Description
-
1Reviews
-
Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Grade

Style

CFM
29
CFM Rated @ 100 PSI
Tank Size
0
Gallons
Grade
Commercial
CFM
29 CFM Rated @ 100 PSI
Tank Size
0 Gallons
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
Features
Features
- Variable Speed Rotary Screw Air System
- 460V 3-phase power drives 1750 RPM motor
- Saves money; great for industrial/manufacturing applications
- Standard Y/Delta Soft Start Motor
- Provides reduced energy demand & amp draw on start up
- Advanced PLC Controller
- Monitors maintenance, temperature, oil level, filtration & hours
- Also monitors remote start/stop
- Spin-Tek
- Unique easy access oil filters & air/oil separators
- No special tools to remove/install saving time and money
- Precision Engineered Rotary Air End
- Highly efficient design provides maximum discharge
- Drive-Tek
- Reduces energy demand up to 33%
- Ultra Quiet Operation
- Provides lower 62 dBA operation than a typical rotary screw
- Designed For Use With Stationary Air Receiver (Not Included)
- 10 year/ 5 year/ 2 year limited Factory Warranty
- 10- air end pump w/service kit; 5- cabinet & motor; 2- electrical
- Must-Have Maintenance Kit To Keep Your EMAX Warranty In Force
- SERVICEKIT001A Maintenance Kit required to validate warranty coverage
Specifications
Motor
Voltage
460 Volt AC
Phase
3-Phase
Amp Draw
Consult Certified Electrician
Recommended Breaker
Consult Certified Electrician
Engine
HP
7.5
Pump
CFM
29
CFM Rated @
100 PSI
Max PSI
150 PSI
Pump Type
Rotary
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Duty Cycle
100%
Tank
Tank Size
0 Gallons
Tank Included
No
Tank Outlet
3/4 Inch
Electronic Drain Valve
No
Tank Orientation
Horizontal
Accessories
Air Dryer
No
Air Filter
No
Overview
Weight
562 Pounds
Certification
UL
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
26 Inches
Product Width
34 Inches
Product Height
43 Inches
Power Type
Electric
Grade

Style

CFM
29
CFM Rated @ 100 PSI
Tank Size
0
Gallons
Grade
Commercial
CFM
29 CFM Rated @ 100 PSI
Tank Size
0 Gallons
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
Features
Features
- Variable Speed Rotary Screw Air System
- 460V 3-phase power drives 1750 RPM motor
- Saves money; great for industrial/manufacturing applications
- Standard Y/Delta Soft Start Motor
- Provides reduced energy demand & amp draw on start up
- Advanced PLC Controller
- Monitors maintenance, temperature, oil level, filtration & hours
- Also monitors remote start/stop
- Spin-Tek
- Unique easy access oil filters & air/oil separators
- No special tools to remove/install saving time and money
- Precision Engineered Rotary Air End
- Highly efficient design provides maximum discharge
- Drive-Tek
- Reduces energy demand up to 33%
- Ultra Quiet Operation
- Provides lower 62 dBA operation than a typical rotary screw
- Designed For Use With Stationary Air Receiver (Not Included)
- 10 year/ 5 year/ 2 year limited Factory Warranty
- 10- air end pump w/service kit; 5- cabinet & motor; 2- electrical
- Must-Have Maintenance Kit To Keep Your EMAX Warranty In Force
- SERVICEKIT001A Maintenance Kit required to validate warranty coverage
Specifications
Motor
Voltage
460 Volt AC
Phase
3-Phase
Amp Draw
Consult Certified Electrician
Recommended Breaker
Consult Certified Electrician
Engine
HP
7.5
Pump
CFM
29
CFM Rated @
100 PSI
Max PSI
150 PSI
Pump Type
Rotary
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Duty Cycle
100%
Tank
Tank Size
0 Gallons
Tank Included
No
Tank Outlet
3/4 Inch
Electronic Drain Valve
No
Tank Orientation
Horizontal
Accessories
Air Dryer
No
Air Filter
No
Overview
Weight
562 Pounds
Certification
UL
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
26 Inches
Product Width
34 Inches
Product Height
43 Inches
Power Type
Electric
Product Specs
+−
Specifications
Motor
Voltage
460 Volt AC
Phase
3-Phase
Amp Draw
Consult Certified Electrician
Recommended Breaker
Consult Certified Electrician
Engine
HP
7.5
Pump
CFM
29
CFM Rated @
100 PSI
Max PSI
150 PSI
Pump Type
Rotary
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Duty Cycle
100%
Tank
Tank Size
0 Gallons
Tank Included
No
Tank Outlet
3/4 Inch
Electronic Drain Valve
No
Tank Orientation
Horizontal
Accessories
Air Dryer
No
Air Filter
No
Overview
Weight
562 Pounds
Certification
UL
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Product Length
26 Inches
Product Width
34 Inches
Product Height
43 Inches
Power Type
Electric
