First Air FAS4T 5-HP 53-Gallon Rotary Screw Air Compressor (230V 1-Phase 150PSI)
Model:
FAS041T
+
Share This Product
Recommended Accessories
Expert Recommended Accessories
Selected by Melissa, our Expert
Optional Accessories
11
Model: 21999-0177
$109.80
In-Stock
Model: 21999-0131
$288.00
Only 1 In-Stock
$1,505.90
Factory-Direct
$2,697.24
Factory-Direct
Model: FA40IH
$231.99
Factory-Direct
$235.00
Factory-Direct
$231.99
Factory-Direct
$249.00
Factory-Direct
$295.00
Factory-Direct
Model: TRI-GD-3046RS-GL
$95.00
Factory-Direct
Model: TRI-GD-4046RS-GL
$108.00
Factory-Direct
Features
Grade
Commercial
Voltage
230 Volt AC
Phase
1-Phase
CFM
16.6
Tank Size
53
- Premium Rotary Air System
- Designed for industrial applications; Economical operation is guaranteed
- High quality components ensures durability with constantly high efficiency
- Continuous 100% Duty Cycle
- Runs your application efficiently 24/7
- Energy Efficient Electric Motor
- Explicitly developed for high loads within industrial applications
- Equipped with energy efficiency driving motors class IE3, protection class IP55, insulation class F
- 3-phase unit is capable of running on 208/230-460 voltage; must be wired on-site by licensed electrician
- High Performance Inlet Filter
- Prevents contaminants from entering the compressor package
- Particles are filtered in two stages: first by centrifugal forces and second by a high efficiency filter element.
- 53 Gallon Air Receiver w/ Low Noise Sound Enclosure For Quiet Operation
- Reduces sounds levels to as low as 65±3 dBA; about the same as a normal conversation
- Service can be conducted quickly and safely from all 4 sides
- High-Efficiency Air Cooling System
- Constructed and measured to be ran up to a room temperature of +45°C
- Improves longevity and reliability
- Integrated Oil Separator
- Guarantees excellent compressed air quality with a remaining oil content of < 3mg/m3
- Oil level can be controlled at all times through inspection glass
- 1 Year Factory Warranty-Parts Only
California residents see
Warning: This product can expose you to chemicals including Cumene which is known to the State of California to cause Cancer, and Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov
Specifications
FAS041T
General Information
Product Category
Air Compressor - Stationary
Motor
Voltage
230 Volt AC
Phase
1-Phase
dBA
dBA
Sound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
68
Magnetic Starter
Magnetic Starter
The Magnetic Starter is the "thinking cap" for the motor of the air compressor. Magnetic starters are electromagnetically operated switches that provide a safe method for certain motors to be started under a large motor load.
Yes
Amp Draw
Consult Certified Electrician
Recommended Breaker
Consult Certified Electrician
Engine
HP
5
Pump
CFM
CFM
Cubic Feet Per Minute, which indicates the compressor's flow rate - or the amount of air that a compressor can produce at a given pressure level. Typically compressors that have higher CFM ratings are able to provide more air, which makes them ideal for larger applications
16.6
CFM Rated @
150 PSI
Max PSI
Max PSI
PSI, or Pounds Per Square Inch, measures the amount of pressure placed on a square inch of space. In compressor terms, PSI is the amount of force that an air compressor can deliver
150 PSI
Oil Sight Glass
Yes
Pump Type
Rotary
After Cooler
After Cooler
An aftercooler is a mechanical heat exchanger designed to remove the heat and moisture of compression from a compressed air stream so the air is cool and dry enough for use in air-operated equipment. A compressed air aftercooler has three primary functions: Cool the air discharged from the air compressor
Yes
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Duty Cycle
100%
Tank
Tank Size
53 Gallons
Tank Included
Yes
Tank Outlet
1/2 Inch
Electronic Drain Valve
Electronic Drain Valve
The inexpensive and reliable electric drain valve (EDV) automatically removes condensate from your air system. It has an integral strainer to prevent clogging and saves time and money by eliminating the need for manual draining
No
Tank Orientation
Horizontal
Accessories
Air Dryer
No
Overview
Product Category
Air Compressor - Stationary
Weight
760 Pounds
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
60 Inches
Product Width
28 Inches
Product Height
62 Inches
Power Type
Electric
Additional Model Numbers
FAS4T, FAS041T
Reviews
(2)
First Air FAS041T Reviews & Ratings
Customer Photos and Videos
Good Compressor / Horrible Instructions / Lose Parts
By Nicholas K.
Sayre, Pennsylvania
Purchased 12/10/2020 |
Review Posted 01/04/2021
The good: this compressor arrived undamaged, well packaged, and easily set. The housing around the unit itself has easy access panels on all 4 sides making MOST parts easy to get to. Something though such as the motor or even the peckerhead are impossible to get to without disassembling the whole thing. Unlike the picture, the compressor was mounted to one side which was a plus so I could add my own air dryer right next to it and there are multiple ports to get air from. It started up easily and all fittings were marked so you know if something came loose or comes loose in the future.
The bad: this compressor is a little quieter than my Quincy 5hp. But not like it is advertised.
It is supposed to have slightly more CFM than the Quincy but actually has less and we had to drop the blast cabinet pressure down to 70psi so it could maintain constant pressure.
The directions were awful. Nowhere in the instructions does it show grounding the machine. There isn't even a place to ground it. We had to use an existing hole and provide our own screw to ground the machine. Startup instructions are vague. Some specs are missing. The guard over the belts was not tight and even after tightening down it vibrates horribly when the machine unloads. We had to pull the cover and put self-stick foam between the cover and housing to get it to stop.
The bad: this compressor is a little quieter than my Quincy 5hp. But not like it is advertised.
It is supposed to have slightly more CFM than the Quincy but actually has less and we had to drop the blast cabinet pressure down to 70psi so it could maintain constant pressure.
The directions were awful. Nowhere in the instructions does it show grounding the machine. There isn't even a place to ground it. We had to use an existing hole and provide our own screw to ground the machine. Startup instructions are vague. Some specs are missing. The guard over the belts was not tight and even after tightening down it vibrates horribly when the machine unloads. We had to pull the cover and put self-stick foam between the cover and housing to get it to stop.
Nicholas K. Recommends This
Was this review helpful?
Rating Breakdown
4/5
4/5
3/5
4/5
Pros:
Durable, Price
Cons:
Bad Instructions
This Is My First Screw Drive
By Scott S.
San Diego, California
Purchased 05/30/2018 |
Review Posted 06/29/2018
This is our first screw drive compressor, so keep that in mind as I have nothing else to compare it to other than the piston compressor it replaced. It is definitely quieter. We've been using it for 3 weeks now and I've been in contact with the manufacturer a couple times for follow-up questions and they've been very helpful. I can't speak to the longevity of the unit as I've only had it a short time, but I'm pleased with the form-factor and it appears to be manufactured well. The instructions are not the best as they're translated into English, so there's certainly room for improvement there. We had it up and running within a couple hours and so far, so good.
Scott S. Recommends This
Was this review helpful?
Rating Breakdown
5/5
5/5
5/5
5/5
Pros:
Easy To Use, Quiet, Price
