Ingersoll Rand 1-1/2" 0.01 Micron High Efficiency Coalescing Compressed Air Filter (235 CFM)
Model: FA400IH
+
Share This Product
-
Product Description
-
Reviews
-
2Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Features
Features
- High Efficiency Oil Removal Filtration
- Particle removal down to 0.01 micron; rated for 235 SCFM at 100 PSI at 100°F
- Including water & oil aerosols; precede with Grade G filter
- Maximum remaining oil aerosol of 0.01 mg/m3 (0.01 ppm) @ 60°F
- Efficient Flow Path
- Deep pleated element design minimizes pressure drop
- Reduced turbulence enhances compressor efficiency
- Zero Clearance Design
- Minimal space requirements install where other filters won't fit
- No-Touch Filter Element
- Efficient operation for up to 1 year between element change-outs
- Element changes are easy- just dump out the old, drop in the new
- Helps reduce overall ownership costs
- All Aluminum Die-Cast Body
- Proprietary coating inside & out protects against corrosion
- Patented Dual Indicator
- Shows differential pressure drop & operating efficiency
- Industrial Grade Automatic Brass Float Drain
- Discharges more reliably than lower quality plastic drains
- Minimum operating temperature 34° F; 176°F maximum
Specifications
Filter
Filter CFM
235
Oil Coalescing
Yes
Inlet Fittings
1-1/2"
Outlet Fittings
1-1/2"
Fitting Size
1-1/2"
High Efficiency
Yes
Overview
Weight
5.2 Pounds
Product Length
5 Inches
Product Width
5.1 Inches
Product Height
16.1 Inches
Features
Features
- High Efficiency Oil Removal Filtration
- Particle removal down to 0.01 micron; rated for 235 SCFM at 100 PSI at 100°F
- Including water & oil aerosols; precede with Grade G filter
- Maximum remaining oil aerosol of 0.01 mg/m3 (0.01 ppm) @ 60°F
- Efficient Flow Path
- Deep pleated element design minimizes pressure drop
- Reduced turbulence enhances compressor efficiency
- Zero Clearance Design
- Minimal space requirements install where other filters won't fit
- No-Touch Filter Element
- Efficient operation for up to 1 year between element change-outs
- Element changes are easy- just dump out the old, drop in the new
- Helps reduce overall ownership costs
- All Aluminum Die-Cast Body
- Proprietary coating inside & out protects against corrosion
- Patented Dual Indicator
- Shows differential pressure drop & operating efficiency
- Industrial Grade Automatic Brass Float Drain
- Discharges more reliably than lower quality plastic drains
- Minimum operating temperature 34° F; 176°F maximum
Specifications
Filter
Filter CFM
235
Oil Coalescing
Yes
Inlet Fittings
1-1/2"
Outlet Fittings
1-1/2"
Fitting Size
1-1/2"
High Efficiency
Yes
Overview
Weight
5.2 Pounds
Product Length
5 Inches
Product Width
5.1 Inches
Product Height
16.1 Inches
Product Specs
+−
Specifications
Filter
Filter CFM
235
Oil Coalescing
Yes
Inlet Fittings
1-1/2"
Outlet Fittings
1-1/2"
Fitting Size
1-1/2"
High Efficiency
Yes
Overview
Weight
5.2 Pounds
Product Length
5 Inches
Product Width
5.1 Inches
Product Height
16.1 Inches
Reviews
+−
Be the First to Write a Review
Do you own this product?
Please share your insights with fellow shoppers.
Please share your insights with fellow shoppers.
Product Q&A
(2)
+−

Search Product Q&A's
Answered by Joshua. the Air Compressor Expert
+−
What kind and size is the filter for my fa490ih?
Rusty Y.
from Oklahoma
August 26, 2019
Answer
The part number needed is 24242273.
Was this answer helpful?
Yes

0
No

0
+−
steve where can i buy replacement filters for the Ingersol rand fa 400ih
James Averyt
from Oklahoma
February 17, 2016
Answer
James,
You can purchase the filter elements (and practically any other Ingersoll-Rand part) from an Ingersoll-Rand Customer Center. They are located throughout the country. I have included a link below to the Customer Center locator on the I-R website.
Ingersoll-Rand Customer Center Locator
You can purchase the filter elements (and practically any other Ingersoll-Rand part) from an Ingersoll-Rand Customer Center. They are located throughout the country. I have included a link below to the Customer Center locator on the I-R website.
Ingersoll-Rand Customer Center Locator
Was this answer helpful?
Yes

0
No

0
