Powerex SEO 40-HP Octoplex Oil-Less Enclosed Scroll Air Compressor (460V 3-Phase 116 PSI)

Powerex SEO 40-HP Octoplex Oil-Less Enclosed Scroll Air Compressor (460V 3-Phase 116 PSI)
Our Price
Compare Prices
Shipping Info
Model: SEO40074
$46,400.00

Factory-Direct
Ships in 2-3 Weeks
Factory items ship direct from the manufacturer.
Shipping times vary.
Shipping Crate Icon
Free Shipping
Add-Ons
+$75.00
Factory-Direct
Ships in 2-3 Weeks
Free Freight
Free Freight
Lift Gate Services
Lift Gate Service
*We currently CANNOT ship this product to Alaska, Hawaii or any destination outside of the United States
Share
  • Product Description
  • Reviews
  • Product Q&A
  • How-To Articles
  • Manuals
Product Description
+
Grade
Commercial
Style
Scroll Compressors
CFM
121.6
CFM Rated @ 100 PSI
Grade
Commercial
CFM
121.6 CFM Rated @ 100 PSI


Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."

Features
Features
  • Completely Oil-Less, Octoplex 100% Duty Cycle Scroll Air Compressor (Not For Medical Use)
  • Eight 5-HP pumps & motors with alternating controls for balanced unit wear & performance up to 116 PSI
  • Delivers completely clean, dry air ideal for manufacturing, pharmaceutical production, labs, etc.
  • WhisperAIR Sound Enclosure Cabinet
  • 60 dBA allows work near the compressor; about the same as a conversation in a restaurant
  • Rigid steel frame has powder-coated panels lined with sound-deadening insulation; vibration isolators reduce noise
  • Programmable, Touch-Screen Logic Controller
  • Operates compressor modules as needed to meet demand with one or more motor/pump compressors
  • Displays hours, high temp & motor overload alarms, run indication, & hours to scheduled maintenance for each module
  • Pressure settings are user adjustable within factory predetermined setting limits
  • Eight 5-HP TEFC, NEMA Motors & Two Inlet Filters With Replaceable Elements
  • Compact footprint, energy efficient operation, low maintenance & environmentally friendly design
  • Motor circuit breakers with lockable disconnects are provided for each compressor module
  • Each inlet filter serves half the compressor modules in the system; located behind an easy-access panel
  • Integral Air-Cooled Aftercooler Design
  • Cools the compressed air, allowing water droplets to condense out of the air flow for drier air
  • Patented Tip Seal Design
  • Yields the highest flow rates and longevity of any other dry scroll compressor
  • Limited Standard Factory Warranty Covers Defects In Materials & Workmanship
  • 12 months / 5,000 hours of use; covers the airend for 36 months / 10,000 hours whichever comes first.
Specifications
Engine
HP
40
Motor
Voltage
460 Volt AC
Phase
3-Phase
dBA
60
Magnetic Starter
Yes
Amp Draw
53.9
Recommended Breaker
Consult Certified Electrician
Pump
CFM
121.6
CFM Rated @
100 PSI
Max PSI
116 PSI
Pump Type
Scroll Compressor
After Cooler
Yes
Pump Drive
Belt Drive
Oil Type
Oil Free
Duty Cycle
100%
Tank
Tank Outlet
1 Inch
Accessories
Pressure Gauge
Yes
Air Dryer
No
Air Filter
Yes
Overview
Weight
2000 Pounds
Certification
UL, NEMA
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
38 Inches
Product Width
58 Inches
Product Height
62 Inches
