Puma 5-HP 60-Gallon (Belt Drive) Single-Stage Air Compressor
Model: PK6560V
Recommended
4.6 out of 54.6 out of 54.6 out of 54.6 out of 54.6 out of 5
Number of Reviews(24)
Write a Review
Q&A (3)
$1,019.00
Free Shipping
&
Lift Gate
  Learn More About Free Freight
Free Shipping & Lift Gate
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 2-3 Weeks
Factory items ship direct from the manufacturer. Shipping times vary.
Shipping to60601
Shipping Details
  • Free to Lower 48 States
  • Lift Gate Service Available - Free Lift Gate Learn More
*We currently CANNOT ship this product to Alaska, Hawaii or any destination outside of the United States
Available Add-Ons
FREE
Learn More
Lift Gate Service
All products weighing more than 100 lbs. ship via semi-truck. We recommend ordering the Lift Gate Service to safely lower the product to the curb. If you have a loading dock or forklift, you do NOT need a Lift Gate service. If you are a residential customer, you must have at least 2-4 able-bodied people present to unload the product. Learn More
Add an Extended Warranty
Excludes CA
Share
  • Product Description
  • 24
    Reviews
  • 3
    Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+−
Grade
Commercial
Style
Single Stage 1-Phase
CFM
15.5
CFM Rated @ 90 PSI
Tank Size
60
Gallons
Grade
Commercial
CFM
15.5 CFM Rated @ 90 PSI
Tank Size
60 Gallons
Features
Features
  • Cast-Iron 1180 RPM 3-Cylinder Pump
  • More durable & longer service life than aluminum pumps
  • Splash lubrication keeps pump running smoother & quieter
  • 3450 RPM Capacitor-Start Motor
  • No need for a expensive magnetic starter
  • Comes equipped with overload protection
  • 208-230V Single Phase
  • Requires at least a 23 amp circuit
  • 230V Plug Not Included
  • Needs to be purchased by customer to meet local code
  • Belt Drive With Sturdy Guard Housing
  • Provides more power, easy to maintain
  • 60 Gallon Vertical Tank
  • ASME & CRN certified for safety to 135 working PSI
  • Convenient 1/2" ball-valve air outlet & 1/4" ball-valve drain
  • Produces 17 CFM At 40 PSI; 15.5 CFM At 90 PSI
  • Ideal for home & professional applications
Specifications
Motor
Voltage
208-230 Volt AC
Phase
1-Phase
Magnetic Starter
No
Amp Draw
Consult Certified Electrician
Recommended Breaker
Consult Certified Electrician
Engine
HP
5
Pump
CFM
15.5
CFM Rated @
90 PSI
Pump Material
Solid Cast Iron
Max PSI
135 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
60 Gallons
Tank Outlet
1/2 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Filter
Regulator
No
Accessories
Pressure Gauge
Yes
Air Dryer
No
Overview
Weight
325 Pounds
Certification
ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
22 Inches
Product Width
31 Inches
Product Height
71 Inches
Power Type
Electric
UPC
0636084165610
Grade
Commercial
Style
Single Stage 1-Phase
CFM
15.5
CFM Rated @ 90 PSI
Tank Size
60
Gallons
Grade
Commercial
CFM
15.5 CFM Rated @ 90 PSI
Tank Size
60 Gallons
Features
Features
  • Cast-Iron 1180 RPM 3-Cylinder Pump
  • More durable & longer service life than aluminum pumps
  • Splash lubrication keeps pump running smoother & quieter
  • 3450 RPM Capacitor-Start Motor
  • No need for a expensive magnetic starter
  • Comes equipped with overload protection
  • 208-230V Single Phase
  • Requires at least a 23 amp circuit
  • 230V Plug Not Included
  • Needs to be purchased by customer to meet local code
  • Belt Drive With Sturdy Guard Housing
  • Provides more power, easy to maintain
  • 60 Gallon Vertical Tank
  • ASME & CRN certified for safety to 135 working PSI
  • Convenient 1/2" ball-valve air outlet & 1/4" ball-valve drain
  • Produces 17 CFM At 40 PSI; 15.5 CFM At 90 PSI
  • Ideal for home & professional applications
Specifications
Motor
Voltage
208-230 Volt AC
Phase
1-Phase
Magnetic Starter
No
Amp Draw
Consult Certified Electrician
Recommended Breaker
Consult Certified Electrician
Engine
HP
5
Pump
CFM
15.5
CFM Rated @
90 PSI
Pump Material
Solid Cast Iron
Max PSI
135 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
60 Gallons
Tank Outlet
1/2 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Filter
Regulator
No
Accessories
Pressure Gauge
Yes
Air Dryer
No
Overview
Weight
325 Pounds
Certification
ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
22 Inches
Product Width
31 Inches
Product Height
71 Inches
Power Type
Electric
UPC
0636084165610
Product Specs
+−
Specifications
Motor
Voltage
208-230 Volt AC
Phase
1-Phase
Magnetic Starter
No
Amp Draw
Consult Certified Electrician
Recommended Breaker
Consult Certified Electrician
Engine
HP
5
Pump
CFM
15.5
CFM Rated @
90 PSI
Pump Material
Solid Cast Iron
Max PSI
135 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
60 Gallons
Tank Outlet
1/2 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Filter
Regulator
No
Accessories
Pressure Gauge
Yes
Air Dryer
No
Overview
Weight
325 Pounds
Certification
ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
22 Inches
Product Width
31 Inches
Product Height
71 Inches
Power Type
Electric
UPC
0636084165610
Reviews
4.6 out of 54.6 out of 54.6 out of 54.6 out of 54.6 out of 5
(24)
+−
Puma PK6560V Reviews & Ratings
96% of Reviewers Recommend This Product
Product Q&A
(3)
+−
Search Product Q&A's Answered by Joshua. the Air Compressor Expert
icon-social-fb1
+−
What country are the compressor pump and motor manufactured in?
Joe
from Florida
January 08, 2020
Answer
The pump is made in Taiwan and the motor is made in Mexico.
Was this answer helpful?
Yes
Thumbs Up Icon
1
No
Thumbs Down Icon
0
+−
How much oil should I put in this compressor?
Ronnie
from Mississippi
January 05, 2019
Answer
21 oz. of oil.
Was this answer helpful?
Yes
Thumbs Up Icon
0
No
Thumbs Down Icon
0
+−
Puma 5-HP 60-Gallon (Belt Drive) Single-Stage Air Compressor $925.00 What's the duty cycle on this unit?
Gary Pennington
from Texas
July 04, 2016
Answer
Most manufacturers do not state the duty cycle of their compressors, but a 50% duty cycle is common for most consumer grade compressors.
We recommend sizing the compressor 1.25-1.5 times the CFM of your tool for continuous operation. If the compressor does not produce enough air volume, CFM, then the pressure will drop.
Reciprocating (Piston) compressors are not designed for continuous or 100% duty cycle. The compressor will cycle off & on if it is sized correctly.
Was this answer helpful?
Yes
Thumbs Up Icon
0
No
Thumbs Down Icon
0
