Schulz ADS 480 Non-Cycling Refrigerated Air Dryer (480 CFM 230V 1-Phase)

Model:

ADS-480

Write a Review
$5,850.00
Free Shipping
  Learn More About Free Freight
Factory-Direct
Ships in 2-5 Business Days
Factory items ship direct from the manufacturer. Shipping times vary.
Schulz ADS 480 Non-Cycling Refrigerated Air Dryer (480 CFM 230V 1-Phase)
Schulz ADS 480 Non-Cycling Refrigerated Air Dryer (480 CFM 230V 1-Phase)
Model: ADS-480
$5,850.00
Features
Specifications
Reviews
Product Q&A
Accessories
How-To Articles
Manuals
Share

Features

Style

Refrigerated

Air Dryer CFM

480


Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
  • Excellent Performance
  • Even where ambient & inlet temperatures are elevated
  • Nominal air pressure of 100 PSI; 203 PSI maximum
  • Energy Efficient Sizing
  • Matches the compressor's displacement, saving energy
  • Electronic Controller
  • Digitally shows temperature & dew point
  • Controls the drain valve through a timer
  • Controls the condenser fan through a probe
  • High-Efficiency Compressor
  • Circulates the refrigerant through the system
  • Totally New Design
  • Delivers high dependability & low power consumption
  • Quick disconnect automatic drain valve doesn't need special tools
  • Requires a 230V, single phase circuit
  • Environmentally Friendly Refrigerant
  • R407c is effective & easier on the environment
  • Compact Footprint
  • Conveniently sized 27x27x44
  • Weighs 317 pounds; simple installation
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
For more information go to: www.p65Warnings.ca.gov

Specifications

ADS-480
specs product image PID-62490
Motor
Voltage
230 Volt AC
Phase
1-Phase
Filter
High Efficiency
Yes
Air Dryer
Air Dryer CFM
480
Max PSI
203
Max Inlet Temp. Rating
100
Max Ambient Temp. Rating
113
Non-Cycling
Yes
Inlet Fittings
2-1/2"
Outlet Fittings
2-1/2"
Aftercooler
No
Pre-Filter
No
Post-Filter
No
Wall Mountable
No
Alarm Lights
Yes
Auto Drain
Yes
Regenerative
No
High Temp
No
Overview
Weight
317 Pounds
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
27 Inches
Product Width
27 Inches
Product Height
44 Inches
Power Type
Electric
