Chicago Pneumatic 7.5-HP 80-Gallon Two-Stage Air Compressor (208-230V 1-Phase)

Chicago Pneumatic 7.5-HP 80-Gallon Two-Stage Air Compressor (208-230V 1-Phase)
Our Price
Compare Prices
Shipping Info
Model: RCP-7581VS
Product Discontinued
Sorry, this product is no longer available.
Continue Shopping With These Categories
Shop All Shop by Style
Discontinued
Sorry, this product is no longer available
Free Freight
Free Freight
Lift Gate Services
Lift Gate Service
*We currently CANNOT ship this product to Alaska, Hawaii or any destination outside of the United States
Share
  • Product Description
  • Reviews
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+−
Grade
Commercial
Style
Two Stage 1-Phase
CFM
23
CFM Rated @ 100 PSI
Tank Size
80
Gallons
Grade
Commercial
CFM
23 CFM Rated @ 100 PSI
Tank Size
80 Gallons


Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."

Features
Features
  • 2 Stage Air Compressor
  • Delivers 23 CFM at 100 PSI; 175 PSI maximum pressure
  • Solid Cast Iron Cylinder, Crankshaft & Valve Plates
  • Rugged components provide long-lasting dependability
  • Aluminum Head & Deep Finned Cooling
  • Unmatched heat dissipation for longer pump life
  • All Units 100% Tested At Full Pressure
  • Provides strong & reliable performance
  • ASME Tank & Safety Valves
  • 80 gallon air reserve for big jobs or multiple users
  • Fully Enclosed Belt Guard
  • Protects the belt & the operator
  • Manual Air Tank Drain
  • Makes tank simple to maintain
  • 208 Volt Or 230 Volt Single-Phase Power
  • Easily wires into either your 208V-1 or 230V-1 system
  • CPXHT25 dryer recommended (not included)
  • 2 Year Factory Warranty
  • Supported by a network of trained service technicians
Specifications
Motor
Voltage
208-230 Volt AC
Phase
1-Phase
Magnetic Starter
Yes
Amp Draw
Consult Certified Electrician
Recommended Breaker
60 Amp Breaker
Engine
HP
7.5
Pump
CFM
23
CFM Rated @
100 PSI
Pump Material
Aluminum w/ Cast Iron Sleeve
Pump Type
Two-Stage
Max PSI
175 PSI
Oil Sight Glass
Yes
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
80 Gallons
Tank Outlet
3/4 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Overview
Certification
ASME
Weight
479 Pounds
Product Length
39 Inches
Product Width
24 Inches
Product Height
77 Inches
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Power Type
Electric
Grade
Commercial
Style
Two Stage 1-Phase
CFM
23
CFM Rated @ 100 PSI
Tank Size
80
Gallons
Grade
Commercial
CFM
23 CFM Rated @ 100 PSI
Tank Size
80 Gallons


Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."

Features
Features
  • 2 Stage Air Compressor
  • Delivers 23 CFM at 100 PSI; 175 PSI maximum pressure
  • Solid Cast Iron Cylinder, Crankshaft & Valve Plates
  • Rugged components provide long-lasting dependability
  • Aluminum Head & Deep Finned Cooling
  • Unmatched heat dissipation for longer pump life
  • All Units 100% Tested At Full Pressure
  • Provides strong & reliable performance
  • ASME Tank & Safety Valves
  • 80 gallon air reserve for big jobs or multiple users
  • Fully Enclosed Belt Guard
  • Protects the belt & the operator
  • Manual Air Tank Drain
  • Makes tank simple to maintain
  • 208 Volt Or 230 Volt Single-Phase Power
  • Easily wires into either your 208V-1 or 230V-1 system
  • CPXHT25 dryer recommended (not included)
  • 2 Year Factory Warranty
  • Supported by a network of trained service technicians
Specifications
Motor
Voltage
208-230 Volt AC
Phase
1-Phase
Magnetic Starter
Yes
Amp Draw
Consult Certified Electrician
Recommended Breaker
60 Amp Breaker
Engine
HP
7.5
Pump
CFM
23
CFM Rated @
100 PSI
Pump Material
Aluminum w/ Cast Iron Sleeve
Pump Type
Two-Stage
Max PSI
175 PSI
Oil Sight Glass
Yes
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
80 Gallons
Tank Outlet
3/4 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Overview
Certification
ASME
Weight
479 Pounds
Product Length
39 Inches
Product Width
24 Inches
Product Height
77 Inches
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Power Type
Electric
Product Specs
+−
Specifications
Motor
Voltage
208-230 Volt AC
Phase
1-Phase
Magnetic Starter
Yes
Amp Draw
Consult Certified Electrician
Recommended Breaker
60 Amp Breaker
Engine
HP
7.5
Pump
CFM
23
CFM Rated @
100 PSI
Pump Material
Aluminum w/ Cast Iron Sleeve
Pump Type
Two-Stage
Max PSI
175 PSI
Oil Sight Glass
Yes
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
80 Gallons
Tank Outlet
3/4 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Overview
Certification
ASME
Weight
479 Pounds
Product Length
39 Inches
Product Width
24 Inches
Product Height
77 Inches
Consumer Warranty
2 Years
Commercial Warranty
2 Years
Power Type
Electric
