Features
Grade
Consumer
Style
Portable - Vertical
CFM
4.0
Tank Size
26
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
Dependable & Quiet Electric Portable Air Compressor
69dBA is ideal for indoor use where noise is an issue
80% quieter than similar oil-free induction products
Produces 4.0 CFM @ 90 PSI; Max 150 PSI
Engineered for high performance and durability
Perfect for larger projects, HVLP spray gun, blowguns, brad and nail guns
Direct Drive 1.5-HP Induction Motor
Designed for maximum performance and efficiency
Tackle airbrushing, drilling, sanding and bolting/wrenching
Oil-Free Single Stage Pump
Up to 4X the life of standard induction oil-free compressors
Provides cleaner air for tool operation and maintenance-free
Low Voltage, Easy Start
Works in a variety of temperatures
Auto on/off switch and safety valve included
26-Gallon Steel Vertical Tank w/ 10" Pneumatic Tires
Compact design for easy portability to job sites
Great for uneven terrains and dampens vibration
Convenient Top Control Panel
Regulator and quick connect right at your finger tips
Dual gauges to monitor tool and tank pressure at a glance
California residents see
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
dBA dBASound levels are measured in decibels (dB). The lower the decibel rating, the less noise the product makes. As an example, a ticking watch is 20 dB while on the other end of the scale, a lawn mower is around 90 dB.
69
Magnetic Starter Magnetic StarterThe Magnetic Starter is the "thinking cap" for the motor of the air compressor. Magnetic starters are electromagnetically operated switches that provide a safe method for certain motors to be started under a large motor load.
No
Amp Draw
12.5
Engine
HP
1.5
Pump
CFM CFMCubic Feet Per Minute, which indicates the compressor's flow rate - or the amount of air that a compressor can produce at a given pressure level. Typically compressors that have higher CFM ratings are able to provide more air, which makes them ideal for larger applications
4.0
CFM Rated @
90 PSI
Pump Material
Aluminum
Max PSI Max PSIPSI, or Pounds Per Square Inch, measures the amount of pressure placed on a square inch of space. In compressor terms, PSI is the amount of force that an air compressor can deliver
150 PSI
Oil Sight Glass
No
Pump Type
Single-Stage
After Cooler After CoolerAn aftercooler is a mechanical heat exchanger designed to remove the heat and moisture of compression from a compressed air stream so the air is cool and dry enough for use in air-operated equipment. A compressed air aftercooler has three primary functions: Cool the air discharged from the air compressor
No
Pump Drive
Direct Drive
Oil Type
Oil Free
Tank
Tank Size
26 Gallons
Tank Outlet
1/4 Inch
Electronic Drain Valve Electronic Drain ValveThe inexpensive and reliable electric drain valve (EDV) automatically removes condensate from your air system. It has an integral strainer to prevent clogging and saves time and money by eliminating the need for manual draining
No
Tank Orientation
Vertical
Filter
Regulator
Yes
Accessories
Pressure Gauge
Yes
Air Dryer
No
Air Filter
Yes
Overview
Product Category
Air Compressor - Portable
Weight
132.3 Pounds
Consumer Warranty
2 Years
Product Length
20.1 Inches
Product Width
23.3 Inches
Product Height
45.5 Inches
Power Type
Electric
