Features
Grade
Contractor
Style
Wheel Barrow
Engine Brand
PowerTrain
CFM
11.2
Tank Size
10
- PowerTrain 7-HP 212cc PT700 OHV Engine
- Automatic stop by oil alert protects your investment
- Cast iron cylinder sleeve, air filter oil bath and EPA & CARB Compliant
- OHV provides more power for easy starting, less fuel-use & lower emissions
- 10-Gallon Capacity Twin Wheelbarrow Style Tanks
- Largest in the industry; powers tools up to 11.2 CFM
- Stable low-profile design is easy to move & transport w/ large flat-free tire
- Solid Cast Iron Pump
- Easy viewing oil sight glass
- “V” Twin style pump delivers 11.2 CFM @ 90 PSI; 150 Max PSI
- 2 Individual & Removable Cylinders
- Allows for easy maintenance
- Delivers smoother and cooler operation
- High-Efficiency Reed Valves
- Offer maximum and reliable performance
- Efficient heat removal from flywheel for cooler running and longer life
- Integrated Control Panel
- Dual 1/4” quick connects lets 2 people work at once
- Built-in regulator and pressure gauges for easier viewing & protection
- Engine Slow-Down Control
- Control and regulates the engine idle speed
- Reduces operating costs and unnecessary wear
- Built For Professional Use
- Sturdy belt guard protects the belt and the user
- Good compressor strength and ability to withstand heavy workloads
California residents see
Warning: This product can expose you to chemicals including Carbon black (airborne, unbound particles of respirable size) which is known to the State of California to cause Cancer.
For more information go to: www.p65Warnings.ca.gov
Specifications
PT-TT70G-CP
Engine
HP
7
CC
212
Auto Idle
Yes
Engine Brand
PowerTrain
Starting System
Recoil Start
Engine Low Oil Shut-off
Yes
Pump
CFM
11.2
CFM Rated @
90 PSI
Pump Material
Solid Cast Iron
Max PSI
150 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
10 Gallons
Tank Outlet
1/4 Inch
Electronic Drain Valve
No
Tank Orientation
Horizontal
Accessories
Pressure Gauge
Yes
Air Dryer
No
Air Filter
Yes
Overview
Weight
190 Pounds
CA (CARB) Compliant
Yes
Consumer Warranty
1 Year
Product Length
50 Inches
Product Width
18 Inches
Product Height
24 Inches
Power Type
Gas
UPC
020791500718
