Quincy 3.5-HP 60-Gallon (Belt Drive) Single Stage Cast-Iron Air Compressor (230V 1-Phase)

Quincy 3.5-HP 60-Gallon (Belt Drive) Single Stage Cast-Iron Air Compressor (230V 1-Phase)
Model: Q13160VQ
$849.99
Factory-Direct
Ships in 2-5 Business Days
Factory items ship direct from the manufacturer.
Shipping times vary.
Free Shipping &
Tax-Free (Except IL)
Add-Ons
+$35.00
Free ShippingNo Sales Tax* (Except IL)$849.99Buy Now
No Sales Tax* (Except IL)$884.99Visit Site
Factory-Direct
Ships in 2-5 Business Days
Free Freight
Free Freight
Lift Gate Services
Lift Gate Service
*We currently CANNOT ship this product to Alaska, Hawaii or any destination outside of the United States
Share
  • Product Description
  • 44
    Reviews
  • 4
    Product Q&A
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Grade
Consumer
Style
Single Stage 1-Phase
CFM
12.8
CFM Rated @ 100 PSI
Tank Size
60
Gallons
Grade
Consumer
CFM
12.8 CFM Rated @ 100 PSI
Tank Size
60 Gallons


Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."

Features
Features
  • Perfect For Commercial Or Do It Yourself Applications
  • Sturdy reliability that lasts and lasts
  • Cast Iron Cylinder, Crankshaft, & Valve Plate
  • Strong & durable single stage compressor
  • Aluminum Head & Special Fin Design
  • Helps dissipate heat; keeps compressor running cool
  • Running cooler lets the unit last longer
  • Start-Stop Pressure Switch
  • Automatically starts the compressor when system pressure drops
  • Develops 14.6 CFM @ 40 PSI; 12.8 CFM @ 100 PSI
  • Plenty of power to run a wide range of air tools
  • 100% factory tested at full pressure
  • Easy To Maintain
  • Shipped with 40-weight lubricant; easy-access manual drain
  • Fully enclosed belt guard protects you & the belt
  • 1 Year Factory Warranty
  • Covers defect in materials & workmanship
  • Quincy "No Bull" Extended Warranty Available
  • Must include EWK-1 Maintenance Kit at time of purchase
  • Must register online; see Warranty PDF under Specs tab for info
Specifications
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
No
Recommended Breaker
30 Amp Breaker
Engine
HP
3.5
Pump
CFM
12.8
CFM Rated @
100 PSI
Pump Material
Aluminum w/ Cast Iron Sleeve
Pump Type
Single-Stage
Max PSI
135 PSI
Oil Sight Glass
Yes
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
60 Gallons
Tank Outlet
1/2 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Overview
Certification
ASME
Weight
261 Pounds
Product Length
30 Inches
Product Width
22 Inches
Product Height
68 Inches
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Power Type
Electric
UPC
791326101563
Grade
Consumer
Style
Single Stage 1-Phase
CFM
12.8
CFM Rated @ 100 PSI
Tank Size
60
Gallons
Grade
Consumer
CFM
12.8 CFM Rated @ 100 PSI
Tank Size
60 Gallons


Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."

Features
Features
  • Perfect For Commercial Or Do It Yourself Applications
  • Sturdy reliability that lasts and lasts
  • Cast Iron Cylinder, Crankshaft, & Valve Plate
  • Strong & durable single stage compressor
  • Aluminum Head & Special Fin Design
  • Helps dissipate heat; keeps compressor running cool
  • Running cooler lets the unit last longer
  • Start-Stop Pressure Switch
  • Automatically starts the compressor when system pressure drops
  • Develops 14.6 CFM @ 40 PSI; 12.8 CFM @ 100 PSI
  • Plenty of power to run a wide range of air tools
  • 100% factory tested at full pressure
  • Easy To Maintain
  • Shipped with 40-weight lubricant; easy-access manual drain
  • Fully enclosed belt guard protects you & the belt
  • 1 Year Factory Warranty
  • Covers defect in materials & workmanship
  • Quincy "No Bull" Extended Warranty Available
  • Must include EWK-1 Maintenance Kit at time of purchase
  • Must register online; see Warranty PDF under Specs tab for info
Specifications
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
No
Recommended Breaker
30 Amp Breaker
Engine
HP
3.5
Pump
CFM
12.8
CFM Rated @
100 PSI
Pump Material
Aluminum w/ Cast Iron Sleeve
Pump Type
Single-Stage
Max PSI
135 PSI
Oil Sight Glass
Yes
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
60 Gallons
Tank Outlet
1/2 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Overview
Certification
ASME
Weight
261 Pounds
Product Length
30 Inches
Product Width
22 Inches
Product Height
68 Inches
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Power Type
Electric
UPC
791326101563
Product Specs
+
Specifications
Motor
Voltage
230 Volt AC
Phase
1-Phase
Magnetic Starter
No
Recommended Breaker
30 Amp Breaker
Engine
HP
3.5
Pump
CFM
12.8
CFM Rated @
100 PSI
Pump Material
Aluminum w/ Cast Iron Sleeve
Pump Type
Single-Stage
Max PSI
135 PSI
Oil Sight Glass
Yes
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
60 Gallons
Tank Outlet
1/2 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Overview
Certification
ASME
Weight
261 Pounds
Product Length
30 Inches
Product Width
22 Inches
Product Height
68 Inches
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Power Type
Electric
UPC
791326101563
Reviews
(44)
+
Quincy Q13160VQ Reviews & Ratings
84% of Reviewers Recommend This Product
Product Q&A
(4)
+
Search Product Q&A's Answered by Jim, the Air Compressor Expert
icon-social-fb1
+
What is the decibel rating on the q13160vq?
Randy Jones
from Washington
October 10, 2016
Answer
I'm sorry- I went all through the manual, the spec sheet, and Quincy's site and I don't see where Quincy has posted a decibel rating for this unit.

There isn't an industry standard (so far) for dBA ratings- so readings could be taken 3 feet away or 10 feet away; in a noisy room or a quiet one. This lack of consistency is one of the reasons many manufacturers won't post a decibel rating.

However- my experience with Quincy piston units is that they are quieter than many others on the market, thanks to quality components and low RPM pumps.

You can see compressors that are built to be quieter than normal in our
Quiet Air Compressor listing.
+
Is this Quincy model made in USA?
Heidi Garren
from Ohio
November 28, 2015
Answer
"Made in USA" is a legal term meaning not only is the item built in the US, but all of the parts must come from the US as well.

Quincy has a long history of US manufacture, but folks keep chasing the lowest cost which has priced Made in USA compressors out of the market.

This compressor is assembled in the US of globally sourced, high-quality components, thoroughly tested and backed by Quincy's Factory Warranty.
+
in the reviews there are recurring issues with the plastic tubes blowing off. Does Quincy have a fix for this? Was considering this compressor, but this seems to be a significant problem.
Lee
from Massachusetts
July 21, 2015
Answer
We checked with Quincy & was told that this design works just fine EXCEPT in cases where the customer is using this machine in excess of the 50/50 duty cycle. The machine is really not designed to run any more than 5 minutes out of 10, and this is true of ALL single stage recip machines. When the duty cycle exceeds the recommended duty cycle, the unloader tube can, in some instances, get hot to the point where it releases from the barbed fitting.
+
Steve- I need a new compressor for my home garage. I will be running a small glass bead cabinet, air shears, impact wrench, air drill, plasma cutter, air grinder, sander, etc.. Only running one tool at a time. I really don't want to spend $1500 on a 5HP dual stage. Will this Quincy 60 Gal, 3.5HP work for me? Many thanks, Lou
Lou Bogdos
from Texas
July 07, 2015
Answer
The model creates 12.3 CFM. Do you have the CFM requirements of your largest tool? I would look those up on your tools. You will then need 1.5X the required air to ensure your compressor can handle all your needs.
