Oasis Manufacturing XDT10-4000-24
Oasis Manufacturing XDT10-4000-24
Hover to zoom
1 Of 5
Oasis 10-Gallon 24-Volt Continuous Duty Air Compressor
Model: XDT10-4000-24
No RatingNo RatingNo RatingNo RatingNo Rating
Number of Reviews(0)
Write a Review
$2,499.00
Free Shipping
Learn More About Free Freight
Free Shipping
*This product qualifies for Free Shipping anywhere in the contiguous US. Accessories may ship separately. Items over 100lbs shipped via semi-truck, be sure to select "Lift Gate" to lower the product to the ground curbside. Remote area surcharges may apply, see our full shipping policy for more details.
Factory-Direct
Ships in 7-14 Business Days
Factory items ship direct from the manufacturer. Shipping times vary.
Shipping to60601
Shipping Details
  • Free to Lower 48 States
  • Lift Gate Service Available - $50.00 Service Charge Learn More
*We currently CANNOT ship this product to Alaska, California, Hawaii or any destination outside of the United States
Available Add-Ons
+$50.00
Learn More
Lift Gate Service
All products weighing more than 100 lbs. ship via semi-truck. We recommend ordering the Lift Gate Service to safely lower the product to the curb. If you have a loading dock or forklift, you do NOT need a Lift Gate service. If you are a residential customer, you must have at least 2-4 able-bodied people present to unload the product. Learn More
Add an Extended Warranty
Excludes CA
Share
  • Product Description
  • Reviews
  • Recommended Accessories
  • How-To Articles
  • Manuals
Product Description
+
Grade
Contractor
Style
DC Compressors
CFM
8
CFM Rated @ 100 PSI
Tank Size
10
Gallons
Grade
Contractor
CFM
8 CFM Rated @ 100 PSI
Tank Size
10 Gallons
Features
Features
  • Designed For Commercial And Industrial Use
  • Made for work trucks and tow trucks
  • Runs On Your 12 Volt DC Vehicle Battery
  • Unit arrives ready to connect to your battery
  • XD 4000 100% Duty Cycle Pump
  • Great for continued, extreme, & construction use
  • Rated at 100% at 100 PSI at 70°
  • Air Breather Assembly (ABA) provides clean intake air
  • 10 Gallon Tank
  • ASME coded tank is ready to bolt down
  • Fan Cooled Motor & Compressor
  • Units that run cooler can run longer & work harder
  • Strong & Compact
  • 2.2 HP motor pushes 8 CFM at 100 PSI
  • Pulls 90 amps of current & 2160 watts at maximum load
  • Measures 40" long x 10" wide x 24" high
  • Maximum pressure is 200 PSI, 150 PSI maximum restart pressu
  • Environmentally Friendly
  • No noisy gas engine or nasty exhaust- just a subdued whir
  • No engine to maintain- doesn't need gas, filters, or spark plugs
Specifications
Motor
Voltage
24 Volt DC
Engine
HP
2
Pump
CFM
8
CFM Rated @
100 PSI
Max PSI
200 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
Tank
Tank Size
10 Gallons
Tank Outlet
3/4 Inch
Tank Orientation
Horizontal
Overview
Weight
110 Pounds
Certification
ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
40 Inches
Product Width
10 Inches
Product Height
24 Inches
Power Type
Electric
Grade
Contractor
Style
DC Compressors
CFM
8
CFM Rated @ 100 PSI
Tank Size
10
Gallons
Grade
Contractor
CFM
8 CFM Rated @ 100 PSI
Tank Size
10 Gallons
Features
Features
  • Designed For Commercial And Industrial Use
  • Made for work trucks and tow trucks
  • Runs On Your 12 Volt DC Vehicle Battery
  • Unit arrives ready to connect to your battery
  • XD 4000 100% Duty Cycle Pump
  • Great for continued, extreme, & construction use
  • Rated at 100% at 100 PSI at 70°
  • Air Breather Assembly (ABA) provides clean intake air
  • 10 Gallon Tank
  • ASME coded tank is ready to bolt down
  • Fan Cooled Motor & Compressor
  • Units that run cooler can run longer & work harder
  • Strong & Compact
  • 2.2 HP motor pushes 8 CFM at 100 PSI
  • Pulls 90 amps of current & 2160 watts at maximum load
  • Measures 40" long x 10" wide x 24" high
  • Maximum pressure is 200 PSI, 150 PSI maximum restart pressu
  • Environmentally Friendly
  • No noisy gas engine or nasty exhaust- just a subdued whir
  • No engine to maintain- doesn't need gas, filters, or spark plugs
Specifications
Motor
Voltage
24 Volt DC
Engine
HP
2
Pump
CFM
8
CFM Rated @
100 PSI
Max PSI
200 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
Tank
Tank Size
10 Gallons
Tank Outlet
3/4 Inch
Tank Orientation
Horizontal
Overview
Weight
110 Pounds
Certification
ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
40 Inches
Product Width
10 Inches
Product Height
24 Inches
Power Type
Electric
Product Specs
+
Specifications
Motor
Voltage
24 Volt DC
Engine
HP
2
Pump
CFM
8
CFM Rated @
100 PSI
Max PSI
200 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
Tank
Tank Size
10 Gallons
Tank Outlet
3/4 Inch
Tank Orientation
Horizontal
Overview
Weight
110 Pounds
Certification
ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
40 Inches
Product Width
10 Inches
Product Height
24 Inches
Power Type
Electric
