Ingersoll Rand Type 30 5-HP 60-Gallon Two-Stage Air Compressor (208V 3-Phase)
Model: 2340L5.200-3
+
Share This Product
-
Product Description
-
11Reviews
-
1Product Q&A
-
Recommended Accessories
-
How-To Articles
-
Manuals
Product Description
+−
Grade
Style
CFM
14.3
CFM Rated @ 175 PSI
Tank Size
60
Gallons
Grade
Commercial
CFM
14.3 CFM Rated @ 175 PSI
Tank Size
60 Gallons
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
Features
Features
- Continuous-Duty Operation Two-Stage Air Compressor
- Provides the reliability and performance
- Perfect solution for commercial, automotive, and light industrial applications with intermittent load deman
- 100% Cast-Iron Cylinders & Pump
- Oversized cast-iron balanced belt wheel and industrial grade bearing
- Long-lasting extended pump life designed for over 15,000 hours of trouble-free use
- Heavy-Duty Pump Comp
- 1-piece connection rod for less moving parts increases reliability
- Precision-balanced overhung crankshaft runs smoothly and quietly
- Easy to repair removable cylinders with 360° radial fins eliminate hot s
- High Efficiency Parts:
- High-efficiency stainless steel valves for increased volumetric efficiency
- High-efficiency inlet air filters with sound attenuation baffles
- High-efficiency intercooler lowers compressed air temperature & reduces condensation
- 60-Gallon ASME Receive
- Manual drain valve simplifies servicing
- Ideal for most applications including machine shops, production lines, car washes & repair shops
- OSHA Compliant
- Fully enclosed flywheel, belt and motor sheave
- All units are prewired and fully tested prior to shipment
- Ingersoll Rand Reciprocating Compressors Ship Dry
- Use of the Ingersoll Rand Maintenance Kit extends the Factory Warranty by 1 year
Specifications
Motor
Voltage
208 Volt AC
Phase
3-Phase
Magnetic Starter
Yes
Amp Draw
17.5
Recommended Breaker
Consult Certified Electrician
Engine
HP
5
Pump
CFM
14.3
CFM Rated @
175 PSI
Pump Material
Solid Cast Iron
Max PSI
175 PSI
Oil Sight Glass
No
Pump Type
Two-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
60 Gallons
Tank Outlet
1/2 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Overview
Weight
435 Pounds
Certification
UL/CSA/ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
24 Inches
Product Width
33 Inches
Product Height
69 Inches
Power Type
Electric
UPC
678384379335
Grade
Style
CFM
14.3
CFM Rated @ 175 PSI
Tank Size
60
Gallons
Grade
Commercial
CFM
14.3 CFM Rated @ 175 PSI
Tank Size
60 Gallons
Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
Features
Features
- Continuous-Duty Operation Two-Stage Air Compressor
- Provides the reliability and performance
- Perfect solution for commercial, automotive, and light industrial applications with intermittent load deman
- 100% Cast-Iron Cylinders & Pump
- Oversized cast-iron balanced belt wheel and industrial grade bearing
- Long-lasting extended pump life designed for over 15,000 hours of trouble-free use
- Heavy-Duty Pump Comp
- 1-piece connection rod for less moving parts increases reliability
- Precision-balanced overhung crankshaft runs smoothly and quietly
- Easy to repair removable cylinders with 360° radial fins eliminate hot s
- High Efficiency Parts:
- High-efficiency stainless steel valves for increased volumetric efficiency
- High-efficiency inlet air filters with sound attenuation baffles
- High-efficiency intercooler lowers compressed air temperature & reduces condensation
- 60-Gallon ASME Receive
- Manual drain valve simplifies servicing
- Ideal for most applications including machine shops, production lines, car washes & repair shops
- OSHA Compliant
- Fully enclosed flywheel, belt and motor sheave
- All units are prewired and fully tested prior to shipment
- Ingersoll Rand Reciprocating Compressors Ship Dry
- Use of the Ingersoll Rand Maintenance Kit extends the Factory Warranty by 1 year
Specifications
Motor
Voltage
208 Volt AC
Phase
3-Phase
Magnetic Starter
Yes
Amp Draw
17.5
Recommended Breaker
Consult Certified Electrician
Engine
HP
5
Pump
CFM
14.3
CFM Rated @
175 PSI
Pump Material
Solid Cast Iron
Max PSI
175 PSI
Oil Sight Glass
No
Pump Type
Two-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
60 Gallons
Tank Outlet
1/2 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Overview
Weight
435 Pounds
Certification
UL/CSA/ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
24 Inches
Product Width
33 Inches
Product Height
69 Inches
Power Type
Electric
UPC
678384379335
Product Specs
+−
Specifications
Motor
Voltage
208 Volt AC
Phase
3-Phase
Magnetic Starter
Yes
Amp Draw
17.5
Recommended Breaker
Consult Certified Electrician
Engine
HP
5
Pump
CFM
14.3
CFM Rated @
175 PSI
Pump Material
Solid Cast Iron
Max PSI
175 PSI
Oil Sight Glass
No
Pump Type
Two-Stage
After Cooler
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Oil System
Splash Lubricated
Pump Low Oil Shut-off
No
Tank
Tank Size
60 Gallons
Tank Outlet
1/2 Inch
Electronic Drain Valve
No
Tank Orientation
Vertical
Overview
Weight
435 Pounds
Certification
UL/CSA/ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
24 Inches
Product Width
33 Inches
Product Height
69 Inches
Power Type
Electric
UPC
678384379335
Product Q&A
(1)
+−
Search Product Q&A's
Answered by Joshua. the Air Compressor Expert
+−
What is the decibel rating on this unit?
Tom
from Pennsylvania
June 15, 2018
Answer
If you would like to get this rating, you can contact Ingersoll directly at 800-483-4981.
Was this answer helpful?
Yes
0
No
2
