Quincy 2-HP 26-Gallon (Belt Drive) Portable Air Compressor

Model:

Q12126VPQ

Recommended
Write A Review
Product Discontinued
Sorry, this product is no longer available.
Try this product instead
Quincy 2-HP 26-Gallon (Belt Drive) Portable Air Compressor
Quincy 2-HP 26-Gallon (Belt Drive) Portable Air Compressor
Model: Q12126VPQ
Product Discontinued
Accessories
Features
Specifications
Reviews
How-To Articles
Manuals
Share

Recommended Accessories

Air Compressors Direct expert image
Expert Recommended Accessories Selected by Melissa, our Expert
Required Accessories 9
These accessories are required to properly setup/install this product.
Optional Accessories 10

Features

Grade

Consumer

Style

Portable - Vertical

CFM

7.4

Tank Size

26



Product Video Disclaimer: "PED is not responsible for any variances from the product in this video and the item you purchase. Please review all product specs prior to purchase."
  • Perfect For Commercial Or Do It Yourself Applications
  • Sturdy reliability that lasts and lasts
  • Cast Iron Cylinder, Crankshaft, & Valve Plate
  • Strong & durable single stage compressor
  • Aluminum Head & Special Fin Design
  • Helps dissipate heat; keeps compressor running cool
  • Running cooler lets the unit last longer
  • Start-Stop Pressure Switch
  • Automatically starts the compressor when system pressure drops
  • 8.3 CFM @ 40 PSI; 7.4 CFM @ 100 PSI
  • Plenty of power to run a wide range of air tools
  • 1/4" Pressure Regulator
  • 100% factory tested at full pressure
  • Easy To Maintain
  • Shipped with 40-weight lubricant; easy-access manual drain
  • 1 Year Factory Warranty
  • Covers defect in materials & workmanship
  • Quincy "No Bull" Extended Warranty Available
  • Must include EWK-1 Maintenance Kit at time of purchase
  • Must register online; see Warranty PDF under Specs tab for info
  • Quincy Part #: 8090253728 Quincy Model #: Q12126VPQ
California residents see
Warning: This product can expose you to chemicals including Lead which is known to the State of California to cause Developmental Harm.
For more information go to: www.p65Warnings.ca.gov

Specifications

Q12126VPQ
specs product image PID-12333
Motor
Voltage
115 Volt AC
Phase
1-Phase
Magnetic Starter Learn More
Magnetic Starter
The Magnetic Starter is the "thinking cap" for the motor of the air compressor. Magnetic starters are electromagnetically operated switches that provide a safe method for certain motors to be started under a large motor load.
No
Amp Draw
19
Recommended Breaker
15 Amp Breaker
Engine
HP
2
Pump
CFM Learn More
CFM
Cubic Feet Per Minute, which indicates the compressor's flow rate - or the amount of air that a compressor can produce at a given pressure level. Typically compressors that have higher CFM ratings are able to provide more air, which makes them ideal for larger applications
7.4
CFM Rated @
100 PSI
Pump Material
Cast Iron w/ Aluminum Head
Max PSI Learn More
Max PSI
PSI, or Pounds Per Square Inch, measures the amount of pressure placed on a square inch of space. In compressor terms, PSI is the amount of force that an air compressor can deliver
135 PSI
Oil Sight Glass
Yes
Pump Type
Single-Stage
After Cooler Learn More
After Cooler
An aftercooler is a mechanical heat exchanger designed to remove the heat and moisture of compression from a compressed air stream so the air is cool and dry enough for use in air-operated equipment. A compressed air aftercooler has three primary functions: Cool the air discharged from the air compressor
No
Pump Drive
Belt Drive
Oil Type
Oil Lubricated
Pump Low Oil Shut-off Learn More
Pump Low Oil Shut-off
Prevents the air compressor from operating or restarting without an adequate amount of oil in the compressor
No
Tank
Tank Size
26 Gallons
Tank Outlet
1/4 Inch
Electronic Drain Valve Learn More
Electronic Drain Valve
The inexpensive and reliable electric drain valve (EDV) automatically removes condensate from your air system. It has an integral strainer to prevent clogging and saves time and money by eliminating the need for manual draining
No
Tank Orientation
Vertical
Overview
Weight
165 Pounds
Certification
ASME
Consumer Warranty
1 Year
Commercial Warranty
1 Year
Product Length
26 Inches
Product Width
26 Inches
Product Height
51 Inches
Power Type
Electric
UPC
791326101556
